Bom185_vKi

ARCHIVE

Bom185_vKi is top of the art high-end mid-woofer, engineered to reproduce the bandwidth from 40Hz to 2000Hz.
- Very low dynamic compression (0.5dB max, from 50Hz to 2000Hz, with 100dB at 1m).
- Very low Inter Modulation Distortion.
- Very low Total Harmonic Distortion, including in low frequency.
- +/- 10mm pure linear excursion.
- Engineered and produced in France

Quantity

Add to cart

Add B-stock to cart

XXX,XX €

XXX,XX €

VAT Excluded

ODM request form

Resonance frequency

FS

38

Hz

Linear response (-3dB)

40 - 2000

Hz

Sensitivity

SPL

90

dB/2.8V/1m

Nominal impedence

8

Ω

Pure linear excursion

Xmax

+/- 10

mm

DC resistance

Re

6.6

Ω

Mechanical quality factor

Qms

6

Total quality factor

Qts

0.32

Force factor

Bl

11.6

N/A

Equivalent volume

VAS

32.2

L

Moving mass

Mms

29

g

Effective area

Sd

193.6

cm2
