Wib70_vHP
Wib70_vHP is a high performances wide band driver, engineered to reproduce 150Hz to 20 000Hz in compact product.
The typical use case is 2x Wib70_vHP, connected in parallel, in sealed enclosure of 0.8L to reach 150Hz at -6dB.
XXX,XX €
XXX,XX €
VAT Excluded
Lead time: 5 - 10 working days
ARCHIVE
This archived product can be ordered with a minimum quantity. If you are interested, please contact us.
Resonance frequency
FS
125
Hz
Linear response (-3dB)
150 - 20000
Hz
Sensitivity
U SPL
85.5
dB/2.8V/1m
Pure linear excursion
X Lin.
+/- 3
mm
Force factor
Bl
4.85
N/A
Inductance at 1KHz
Le
0.08
mH
Moving mass
Mms
2.5
g
Total quality factor
Qts
0.47
Mechanical quality factor
Qms
6.8
DC resistance
Re
6.1
Ω
Nominal impedence
8
Ω
Equivalent volume
VAS
0.45
L
Effective area
Sd
22
cm2
