Lom120_vMS
ARCHIVE
Lom120_vMS is a Mid-woofer engineered to reproduce 80Hz - 4000Hz (-6dB) in 3 ways system.
It uses a Ø26mm, very light, non-inductive Polyimide voice coil former and CCA wire.
It provides extended bandwidth due to low moving mass and very low inductance (Le=0.15mH at 1KHz).
The reversed half roll surround is made of low lost NBR for improved transient response.
The cone is made of damped hexaKone paper, allying low weight (cone alone = 1.2g), high rigidity and efficient damping.
Lom120_vMS has excellent matching with drivers references Sub180_vMS and Twt28_vMS.
XXX,XX €
XXX,XX €
VAT Excluded
Lead time: 5 - 10 working days
This archived product can still be ordered with a minimum quantity of 300 units.
If you are interested, please contact us.
Resonance frequency
FS
72
Hz
Linear response (-3dB)
80 - 4000
Hz
Sensitivity
U SPL
90.5
dB/2.8V/1m
Pure linear excursion
X Lin.
+/- 4
mm
Force factor
Bl
5.2
N/A
Inductance at 1KHz
Le
mH
Moving mass
Mms
5.5
g
Total quality factor
Qts
0.351
Mechanical quality factor
Qms
7.5
DC resistance
Re
4
Ω
Nominal impedence
6
Ω
Equivalent volume
VAS
3.51
L
Effective area
Sd
52.8
cm2
