Cox135_vPA-S
ARCHIVE
Advanced 28mm soft dome tweeter producing very dynamic and natural sounding.
With its very flat response from 1800Hz to 22000Hz (-3dB) and its very low THD from 3000Hz, the Twt28_vMS is the ideal solution for accurate studio monitor loudspeaker, or High-End system.
We recommend high pass filter around 3kHz, 12dB/Oct. to get the best performances.
XXX,XX €
XXX,XX €
VAT Excluded
Lead time: 5 - 10 working days
This archived product can still be ordered with a minimum quantity of 300 units.
If you are interested, please contact us.
Resonance frequency
FS
158
Hz
Linear response (-3dB)
160 - 20000
Hz
Sensitivity
U SPL
91
dB/2.8V/1m
Pure linear excursion
X Lin.
+/- 3
mm
Force factor
Bl
8.78
N/A
Inductance at 1KHz
Le
mH
Moving mass
Mms
9.4
g
Total quality factor
Qts
0.59
Mechanical quality factor
Qms
2.36
DC resistance
Re
6.5
Ω
Nominal impedence
8
Ω
Equivalent volume
VAS
1.38
L
Effective area
Sd
95
cm2
